Yh-C52 Ly500 500kg Cargo Transport Drone

2

Flight control

professional flight control system (including GPS, high-definition RTK image transmission, and camera).

3

Remote control

Yunzhuo H30 Integrated Digital Remote Control (10-inch screen, maximum control range 50 km) Dual Remote Controls

4

Power kit

G110 power sleeve, rated tensile force 110 kilograms, 12 sets

5

Battery

One set of batteries(12), 24S voltage, Recommended is 12*24S*67000mah, approximately 72 KWH of electricity

6

Charger

12 3kW 24s chargers

2

Maximum load

600kg

12

Battery life

43 minutes (no load, retain 15% battery)
33 minutes (100kg load, retain 15% battery)
30 minutes (200kg load, retain 15% battery)
25 minutes (300kg load, retain 15% battery)
21 minutes (400kg load, retain 15% battery)
18 minutes (500kg load, retain 15% battery)

3

Maximum takeoff weight

1080kg

13

Charger power

3000w*4/6000*2

4

Layout wheelbase

3900mm

14

fuselage material

T700 (carbon fiber, 75 aluminum alloy)

5

Remote control

Yunzhuo H30 Integrated with digital screen (7-inch screen, maximum control distance 40km)

15

power kit

G110 power sleeve, rated tensile force 110 kilograms, 12 sets

6

Folded body dimensions

2000*2000*1800

16

operating voltage

100S

7

bare device weight

260kg

17

battery material

Semi-solid mechanism, PVC casing

8

battery weight

240kg

18

Main features

One-click takeoff, one-click landing, and out-of-control return
Real-time view of aircraft flight status, images, video, voltage, coordinates, altitude, speed, distance, etc

9

Flight distance

0-10km

19

propeller size

1868mm (72 inches)

10

Flight altitude

0-1500m

20

propeller material

carbon fiber
