Product Description
Overview
The YH-A23 ND10 deception unmanned aerial vehicle (UAV) defense device generates simulated deceptive satellite navigation signals and acts on the satellite navigation system of the "unauthorized flight" UAV, forcing the target to fail to fly along the original path and guiding it in the designated direction to achieve targeted displacement, rejection and other measures, ensuring the safety of the low-altitude protected area.
This product has been approved and certified by the National Radio and Television Commission and is suitable for the disposal of target drones in important economic zones, smart parks, government and enterprise parks, power and petrochemical parks, large-scale events and other scenarios.
Product parameters
Working mode | Navigation deception |
Range of action | <500m(omnidirectional) |
Supported frequency bands | GPS L1, GLONASSL1 |
Signaltransmission power | <10dBm(adjustable) |
Direction Finding Accuracy | Moving ≤ 10°, Hovering ≤ 3° |
Target induction quantity | >10 sortings(simultaneously) |
Overall power consumption | <30W |
Equipment weight | ~ 20kg |
Simultaneous Detection | ≥30 Drone |
Protection grade | lP65 |
Voltage | AC 110V to 220V±20V |
Operating temperature | -40 to 70°C |
Equipment dimensions | 400mm*332mm*110mm |
